Wireless internet service providers, camp and compound operators, and integrators connecting buildings across a site all need the same three things: a core router that can shape thousands of subscribers, radios that carry the traffic between towers and rooftops, and customer units on each roof. In the UAE that stack is almost always built from MikroTik and Ubiquiti airMAX, because both deliver carrier-grade performance at prices that make a 50-subscriber network viable. This guide lays out the equipment layer by layer with current Dubai prices.
The four layers of an ISP or campus wireless network
| Layer | Job | Typical equipment |
|---|---|---|
| Core router | Terminates the internet uplink, runs PPPoE or hotspot for subscribers, queues bandwidth per customer, routes between towers | MikroTik CCR series |
| Backhaul | High-capacity point-to-point link between the core and each tower or building | Ubiquiti airFiber, PowerBeam; MikroTik LHG XL |
| Sector / base station | Radiates coverage from the tower to many customers | MikroTik mANTBox; Ubiquiti Rocket, LiteAP |
| Customer premises (CPE) | Rooftop unit at each subscriber pointing at the tower | Ubiquiti LiteBeam, NanoStation, Loco; MikroTik SXT |
Core routers: the MikroTik CCR line
The Cloud Core Router is where RouterOS earns its reputation: PPPoE server, per-subscriber queues, BGP with your upstream, and dual-ISP failover, all in one box with a permanent Level 6 licence.
| Model | Fit | Price |
|---|---|---|
| CCR2004-16G-2S+ | Up to a few hundred subscribers, 16 gigabit ports, 2x 10G SFP+ | AED 1,668 |
| CCR1009-7G-1C-1S+ | Compact 9-core core for smaller WISPs and compounds | AED 2,024 |
| CCR1036-12G-4S | 36-core, thousands of queues, 12 gigabit + 4 SFP | AED 4,198 |
| CCR1036-8G-2S+EM | 36-core with 16GB RAM and 10G uplinks for the largest networks | AED 5,440 |
Between towers, a CRS328-4C-20S-4S+RM (AED 1,518) aggregates fibre and SFP+ uplinks, and a CRS328-24P-4S+RM PoE switch (AED 1,990) powers radios and cameras on the mast.
Backhaul: moving capacity between sites
For links of several kilometres carrying hundreds of megabits, Ubiquiti airFiber is the standard. The airFiber 5XHD (AED 1,679 per end) delivers a gigabit-class licensed-free link; the airFiber 4X (AED 1,478) works in the 4.9 GHz band. For shorter or lower-capacity hops, a pair of PowerBeam 5AC-620 dishes (AED 897 each, 29 dBi) or PowerBeam 5AC Gen2 (AED 529 each) is the cost-effective choice, and MikroTik’s LHG XL 5 ac grid antennas (4-pack, AED 1,587) suit long dusty links where a solid dish loads the mast.
Sector antennas: covering customers from the tower
A tower typically carries three or four sectors of 90 to 120 degrees each. MikroTik mANTBox 19s (AED 748) is an integrated 19 dBi 120-degree sector with SFP, popular because it runs RouterOS like the core. On the Ubiquiti side, the Rocket 5AC Lite (AED 500) pairs with an airMAX sector antenna, and the LiteAP LAP-120 (AED 391) is an all-in-one 120-degree sector for smaller cells. For 360-degree coverage of a compound, the OmniTIK 5 PoE (AED 345) also powers cameras from its ports.
Customer units: what goes on each roof
| Distance to tower | CPE | Price |
|---|---|---|
| Under 2 km, dense area | NanoStation Loco 5AC | AED 247 |
| 2 to 5 km | NanoStation 5AC or MikroTik SXTsq Lite5 | AED 489 / AED 155 |
| 5 to 15 km | LiteBeam M5-23 or LiteBeam 5AC Gen2 | AED 182 / AED 380 |
| 15 km and beyond | PowerBeam 5AC Gen2 or MikroTik QRT 5 | AED 529 / AED 598 |
Every outdoor unit should get an ETH-SP surge protector (AED 86) at the building entry. Gulf summer storms and dust static are the top cause of dead radios.
Volume pricing: the LiteBeam M5-23 and hAP RB951Ui are stocked in the hundreds specifically for ISP rollouts. Dealer pricing starts at 50 units. Because we are the master distributor, resellers and integrators buy at the same source price whether they order 50 or 500.
Frequently asked questions
What equipment does a small ISP in the UAE need to start?
A MikroTik CCR2004 core router, one PowerBeam or airFiber backhaul link per tower, a mANTBox or Rocket sector per direction, and a LiteBeam or NanoStation on each customer roof, plus PoE switches and surge protectors on the mast.
Which MikroTik router is best for an ISP?
The CCR2004-16G-2S+ for networks up to a few hundred subscribers and the CCR1036 series for thousands. Both carry a permanent Level 6 RouterOS licence with unlimited queues and PPPoE users.
Is Ubiquiti airMAX still used for ISP links?
Yes. airMAX ac radios such as the LiteBeam 5AC Gen2 and PowerBeam 5AC Gen2 remain the most widely deployed fixed-wireless CPE in the region because of their price and reliability.
Do you supply ISP equipment across the UAE?
Yes. High Speed Dimension Technologies supplies MikroTik and Ubiquiti to ISPs, camps and integrators in all seven emirates from stock in Dubai, with free delivery and UAE VAT invoicing.
Building or expanding a wireless network?
Send us the tower map and subscriber count. We will size the core, the backhaul and the CPE, and quote at distributor prices.
